The energy-saving LED lighting provides optimal visibility for your workspace so you can concentrate on your next masterpiece.
Technical Overview
Installation type
Wall-mounted
Type of appliance width
90 cm
Colour of appliance
Stainless steel
Sound power at max. speed (2010/30/EC)
65 dB
Maximum output air extraction
365 m³/h
Ventilation type
Convertible
Home Connect
No
General information
Type of appliance width
90 cm
Color body
Stainless steel
Installation type
Wall-mounted
Ventilation type
Convertible
Total power of the motors
95 W
Controls
push-button
Number of speed settings
3
Maximum output air extraction
365 m³/h
Sound power at max. speed (2010/30/EC)
65 dB
Maximum output recirculating air
213 m³/h
Sound power at max. speed (recirculation)
67 dB
Grease filter material
Washable aluminium
Energy efficiency rating
D
Total annual energy consumption
53.1 kWh/annum
Height of the appliance
246 mm
Width of the appliance
900 mm
Dimensions
500 mm
Height of the chimney
553-730/573-730 mm
Minimum distance above an electric hob
550 mm
Minimum distance above a gas hob
650 mm
Diameter of air outlet
120 / 150 mm
No-return airflow flap
No
Length electrical supply cord
130.0 cm
Weight
10.8 kg
Appliance height exhaust air max
975 mm
Appliance height exhaust air min
799 mm
Appliance height recirculating max
975 mm
Appliance height recirculating min
799 mm
